23 LED Side Emitting Module
DC12V • 23 LEDs • IP20 • High-Brightness LED Module for Slim Light Boxes & Double-Sided Signs
Hero Banner
High-Efficiency Side Lighting for Professional Signage
The 23 LED Side Emitting Module is designed to provide bright, uniform edge illumination for slim light boxes, double-sided advertising signs, and commercial wayfinding systems. With a compact aluminum PCB, high-transmittance optical lens, and low-voltage DC12V operation, it delivers reliable performance for professional sign manufacturers.
Ideal Applications
- Slim Light Boxes
- Double-Sided Advertising Signs
- Wayfinding Systems
- Acrylic Signage
- Retail Displays
- Shopping Mall Signs
- Exhibition Displays
- Commercial Branding
Why Choose the 23 LED Side Emitting Module?
Optimized Side-Light Optical Design
The specially designed side-emitting optical structure directs light evenly across narrow sign cabinets, improving brightness uniformity while reducing dark areas.
Key Benefits
- Uniform edge illumination
- Improved light utilization
- Reduced hotspots
- Suitable for slim sign structures
- Professional lighting performance
High-Brightness SMD2835 LEDs
Premium SMD2835 LEDs deliver high luminous efficiency with stable color consistency and low power consumption.
Advantages
✔ High brightness
✔ Low energy consumption
✔ Stable color output
✔ Long service life
Durable Aluminum PCB
The aluminum PCB enhances heat dissipation, improving reliability during long-term operation.
Thermal Advantages
- Faster heat transfer
- Stable brightness
- Reduced LED degradation
- Longer product lifespan
Product Features
Uniform Side Illumination
Engineered for edge-lighting applications where consistent brightness is essential.
Compact Design
Slim module profile allows installation inside narrow sign cabinets and light boxes.
Easy Installation
Dual-end wiring design supports fast installation and convenient series connection.
Reliable Performance
Manufactured under strict quality control to ensure stable performance in commercial projects.
Technical Specifications
Please verify these specifications with your product datasheet before publishing.
|
Item |
Specification |
|
Product Name |
23 LED Side Emitting Module |
|
LED Type |
SMD2835 |
|
LED Quantity |
23 LEDs |
|
Light Direction |
Side Emitting |
|
Voltage |
DC12V |
|
Waterproof Rating |
IP20 |
|
Lens Material |
High-Transmittance PC Optical Lens |
|
PCB Type |
Aluminum PCB |
|
Beam Angle |
Side Emitting |
|
Color Temperature |
6500K (Custom Available) |
|
Color Rendering Index |
Ra ≥ 80 |
|
Working Temperature |
-20°C ~ +60°C |
|
Lifespan |
50,000 Hours |
|
Warranty |
3 Years |
|
Certifications |
CE, RoHS |
Product Advantages
High Light Uniformity
Designed for slim advertising light boxes requiring consistent illumination.
Efficient Heat Dissipation
Aluminum PCB maintains stable operating temperatures and extends service life.
Energy Saving
Low-voltage operation helps reduce overall power consumption.
Commercial Reliability
Suitable for continuous operation in retail and commercial environments.
Recommended Applications
Double-Sided Light Boxes
Ideal for advertising displays with edge-lighting requirements.
Wayfinding Signage
Suitable for airports, hospitals, office buildings, metro stations, and shopping centers.
Acrylic Signs
Provides clean, even illumination for acrylic letters and sign panels.
Retail Displays
Perfect for illuminated product displays and commercial branding.
OEM & ODM Manufacturing
We provide complete OEM & ODM services:
- Private Label Branding
- Custom Color Temperature
- Custom Wire Length
- Customized Packaging
- Bulk Production
- Distributor Programs
- Technical Support
- Project-Based Manufacturing
Packaging Information
|
Item |
Standard |
|
Packaging |
Anti-Static Bag |
|
Inner Packaging |
Standard Export Box |
|
Carton |
Export Carton |
|
OEM Packaging |
Available |
Quality Assurance
Each module is tested through:
- 100% Functional Test
- Aging Test
- Brightness Consistency Inspection
- Electrical Safety Test
- Final Quality Inspection
Frequently Asked Questions
Q1: What applications is this module designed for?
It is ideal for slim light boxes, double-sided advertising signs, acrylic signage, and commercial wayfinding systems.
Q2: Is this module waterproof?
This model is rated IP20 and is intended for indoor applications. Waterproof versions are available for outdoor projects.
Q3: Can the color temperature be customized?
Yes. Warm White, Neutral White, Cool White, and custom colors are available for OEM orders.
Q4: Do you provide OEM and ODM services?
Yes. We support custom branding, packaging, wiring, and project-specific product development.
Q5: What certifications does the product have?
The module complies with CE and RoHS standards, making it suitable for international markets.
Request a Wholesale Quote
Your Reliable LED Signage Lighting Partner
The 23 LED Side Emitting Module combines high efficiency, stable performance, and professional optical design, making it an ideal solution for manufacturers of illuminated signs, advertising light boxes, and commercial display systems.
Why Choose JHG?
✔ Factory Direct Pricing
✔ Professional OEM & ODM Services
✔ Strict Quality Control
✔ Fast Production Lead Time
✔ Worldwide Export Experience
✔ Technical Support for B2B Projects
Contact us today for samples, technical specifications, bulk pricing, and customized lighting solutions.
